insulations: polyethylen
Thermasheet FR
Thermasheet FR insulating board made of high quality LDPE polyethylene with closed cell structure, obtained in the process of crosslinking. Mounted with Thermaglue adhesive, it is recommended to use Thermatape FR tape to finish the joints.
Thermasheet FR is used to insulate:
- round and square cross-sections,
- round and oval air strokes,
- air treatment systems,
- refrigeration equipment,
- tanks, valves, elbows,
- large diameter pipes in heating and cooling installations
Thermasheet FR is a variant of mats (plates) equipped with a self-adhesive layer protected with a suitable material. The use of these products allows for quick and clean assembly.
Attention! When choosing a product option, the self-adhesive version is marked SA.
| Density | 35 kg/m3 |
| Color | grey |
| Thermal conductivity | 0,035 W/mK when 10 °C
0,038 W/mK when 40 °C |
| Working temperature | -80oC do 110oC |
| Resistance to water vapor dysfusion (μ) | >3500 |
| UV resistance | perfect after using Thermaflex 800 paint |
| Resistance to ozone | excellent |
| Scent | neutral |
| Chemical resistance | very good |
| Flexibility | good |
| Thermal stability | contractility < 0,5% |
| Toxicity in fire | no |
| Gas emission with complete combustion | 99% CO2 i H2O |
| Fire categories | non-inflammable |
| B1 |
| Thickness [mm] | Roll length [m] | m2 in the roll |
| 5 | 200 | |
| 7,5 | 100 | |
| 10 | 70 | |
| 13 | 60 | |
| 15 | 50 | |
| 20 | 35 | |
| 25 | 30 | |
| 30 | 25 | |
| 38 | 20 | |
